Technical Parameters
Temperature range: 300 ℃ ~ 1200 ℃
Furnace inner size: φ40mm×1000mm
Temperature field index: the end of the uniform temperature field is less than 100mm from the furnace mouth, and the length of the uniform temperature field of ± 20 ℃ is greater than 400mm
Dimensions: 1010mm × 305mm × 365mm
Scope of application: Annealing of standard thermocouples, working precious metal thermocouples, etc.
DTL-TG Type Thermocouple Annealing Furnace test basis:
"JJG75-1995 Standard Platinum and Rhodium 10-Pt Thermocouple Verification Regulations" "JJG167-1995 Standard Platinum and Rhodium 30-Pt Rhodium 6 Thermocouples Verification Regulations" "JJG141-2013 Working Precious Metal Thermocouple Verification Regulations"
